Review of smartphones K-Touch

K-Touch Hornet Touch

K-Touch W806+ Hornet
K-Touch W806+ Hornet

K-Touch Hornet Touch - a new flagship smartphone from the company K-Touch.

K-Touch Hornet Touch is equipped with a 4-core processor Nvidia Tegra 3 with a frequency of 1.5 GHz, 1 GB of RAM and 16 GB of internal memory.

IPS display diagonal of 5.7 inches, a resolution of 1280 × 720 pixels. The front camera has a 1 megapixel, rear - 8 megapixels with autofocus and flash.

The smartphone is equipped with standard modules Wi-Fi, Bluetooth and GPS.

Powerful filling K-Touch Hornet Touch is powered by a battery capacity of 2800 mAh, the body thickness is 10.8 mm. Is running Android 4.0 ICS.

K-Touch V8 - Hornet II

K-Touch Hornet II
K-Touch Hornet II

K-Touch V8 - Hornet II - a new and exciting Chinese smartphone based on the four core processor Nvidia Tegra 3 which has four cores at 1.4GHz and also has a fifth core at 500mhz, which operates at a slack load, thereby providing a low Energy consumption. This processor is installed in devices such as: ASUS Transformer Pad, Acer Iconia Tab A510, Google Nexus 7, ZTE Era, ZTE T98, ASUS Eee Pad Transformer Prime, Acer Iconia Tab A700 / A701, HTC One X, LG Optimus 4X HD, ZTE PF 100, Asus Transformer Pad Infinity

So do not let us down and GPU ULP GeForce, which consists of 12 cores.

The smartphone has a 4.5 inch display with HD resolution 720x1280px.

Two cameras: front 1.3mpx, and back in 8mpx, moreover, it supports video recording in Full HD resolution.

The battery is good, its capacity 1800mah.

The smartphone runs on OS Android 4.0
